Class II B2 Biological Safety Cabinet Biobase

Advantage:

1. Time reserve function.
2. Motorized front window.
3. ULPA filter life and UV life indicator.
4. Automatic air speed adjustable with filter block.
5. With memory function in case of power-failure.
6. Work area surrounded by negative pressure, it can ensure maximum safety in work area.
7. Most accessories are standard, which saves your money. There is no need to pay more.
8. Audio and visual alarm (filter replacement, window over height, abnormal air flow velocity, etc).
9. Remote control. All functions can be realized with it, making the operation much easier and more convenient.
10. Interlock function: UV lamp and front window; UV lamp and blower, fluorescent lamp; blower and front window.

11. Foot switch. Adjust front window height by foot during experiment, to avoid airflow turbulence caused by arm movement.


Models:



Model

BSC-1100IIB2-X

BSC-1300IIB2-X

BSC-1500IIB2-X

BSC-1800IIB2-X

External Size

(W*D*H)

1100*750*2250mm

1300*750*2250mm

1500*750*2250mm

1800*775*2250mm

Internal Size

(W*D*H)

940*600*660 mm

1150*600*660 mm

1350*600*660mm

1625*600*660 mm

Tested Opening

Safety Height 200 mm(8’’)

Max Opening

420mm(17’’)

420mm(17’’)

500mm(20’’)

480mm(20’’)

Inflow Velocity

0.53±0.025 m/s

Down flow Velocity

0.33±0.025 m/s

ULPA Filter

Two, 99.9995% efficiency at 0.12 μm,filter life indicator.

Front Window

Motorized,two-layer laminated toughened glass ≥ 6mm,anti UV.

Noise

≤ 67 dB

UV Lamp

30W*1

30W* 1

40W* 1

40W*1

UV timer, UV life indicator, emission of 253.7 nanometers

for most efficient decontamination.

Illuminating Lamp

LED Lamp

12W*2

12W*2

16W*2

16W*2

Illumination

≥1000Lux

Consumption

800W

850W

1300W

1300W

Waterproof Sockets

Two, total load of two sockets: 500W

Display

LCD display: exhaust filter and downflow filter pressure, filter and UV lamp working time,

inflow and downflow velocity, filter life, humidity and temperature, system working time etc.

Control System

Microprocessor

Airflow System

0% air recirculation, 100% air exhaust

Alarm

Abnormal airflow velocity; Filter replacement; Front window at unsafe height.

Exhaust Duct

4 meters PVC duct, Diameter:300mm

Material

Work Zone: 304 stainless steel

Main Body: Cold-rolled steel with anti-bacteria powder coating.

Work Surface Height

750mm

Caster

Foot master caster

Power Supply

AC 220V±10%, 50/60Hz; 110V±10%, 60Hz (110V/60Hz is not applicable to BSC-1800IIB2-X)

Standard Accessory

Illuminating lamp, UV lamp*1,base stand, remote control, foot switch, exhaust blower,

exhaust duct, drain valve, waterproof sockets*2, pipe strap*2

Optional Accessory

Water and gas tap, Electric height adjustable base stand

Gross Weight

240kg

280kg

300kg

408kg

Package

Main Body

1220* 1000* 1820 mm

1460*1000*1820 mm

1630*1000*1820 mm

1930*1000*1820 mm

Exhaust Blower (W*D*H)

970* 810* 630 mm

970* 810* 630 mm

970* 810* 630 mm

970* 810* 680 mm
